The backend

The backend is the control panel for your frames. You use it to design scenes, deploy them over SSH, and manage them through FrameOS Remote when they connect back to the backend. It's a single self-hosted web app that runs on your own machine and needs no account. Don't want to host anything? FrameOS Cloud is the hosted alternative, and a standalone frame needs neither - the backend is the most capable of the three, and the one to pick for compiled Nim apps, custom drivers, a terminal on the frame, and ESP32 firmware builds.

A few things worth knowing up front:

• The backend needs network access to your frames for first deploys and direct status checks (SSH and HTTP). After FrameOS Remote is installed, frames can also connect back to the backend over an outbound WebSocket.
• The backend does not need to stay running. Frames work fully standalone after a deploy. Keeping it running gets you log aggregation, metrics, and one-click redeploys.

Quick install

The easiest way to install on a Mac or a Debian/Ubuntu Linux machine:

bash <(curl -fsSL https://frameos.net/install.sh)

The script installs Docker if needed, then runs the frameos/frameos container on port 8989. Once it's up, open http://localhost:8989 on that same machine (or http://<its-ip>:8989 from another device) and create your local account.

Home Assistant add-on

If you run Home Assistant, FrameOS is one click away:

1. Go to Settings → Add-ons → Add-on Store in Home Assistant.
2. Click the ⋮ menu in the top right corner and select Repositories.
3. Add https://github.com/FrameOS/frameos-home-assistant-addon.
4. Find FrameOS in the add-on list, click Install, then Start.
5. Optionally enable Start on boot and Watchdog.
6. Click Open Web UI.

The add-on deploys precompiled release binaries; it has no Docker socket, so building FrameOS from source needs a build host configured under Settings → Builds. Browser flashing of ESP32 boards needs the add-on reached over https:// or localhost - behind plain-http:// ingress there is no Web Serial.

Running via Docker manually

This is what the install script does under the hood:

# generate a stable secret key
SECRET_KEY=$(openssl rand -base64 32)
mkdir -p db

# run the latest release
docker run -d --name frameos --restart always \
    -p 8989:8989 \
    -v ./db:/app/db \
    -e SECRET_KEY="$SECRET_KEY" \
    frameos/frameos:latest

Then open http://localhost:8989 and create your local account.

To keep the container automatically up to date, add watchtower:

docker run -d --name watchtower \
    -v /var/run/docker.sock:/var/run/docker.sock \
    containrrr/watchtower --interval 86400 frameos

Faster builds with Docker access

SD card image generation works in the default container without extra privileges. If you also want the backend to cross-compile FrameOS from source in local build containers (instead of using precompiled binaries or building on the device), give it access to Docker:

SECRET_KEY=$(openssl rand -base64 32)
mkdir -p db /tmp/frameos-cross

docker run -d --name frameos --restart always \
    -p 8989:8989 \
    -v ./db:/app/db \
    -v /tmp/frameos-cross:/tmp/frameos-cross \
    -v /var/run/docker.sock:/var/run/docker.sock \
    --privileged \
    -e TMPDIR=/tmp/frameos-cross \
    -e SECRET_KEY="$SECRET_KEY" \
    frameos/frameos:latest

This is optional: for common targets FrameOS ships precompiled binaries, and you can also configure remote SSH build servers, or build on the frame itself, under Settings → Builds.

Local development with Flox

Use this path when you want to work on FrameOS itself instead of running the released Docker image. The repository ships a checked-in Flox environment that installs the Python, Node, pnpm, Nim and Redis tooling used by the backend and frontend.

git clone https://github.com/FrameOS/frameos.git
cd frameos
flox activate
pnpm dev

flox activate creates a repo-local .venv, installs backend/requirements.txt, runs pnpm install --frozen-lockfile, and installs the Nim dependencies for both the frame runtime and FrameOS Remote. The activation hook reruns only when the lockfiles or package definitions change.

pnpm dev opens an mprocs dashboard with the local services:

• backend - FastAPI on http://localhost:8989 with DEBUG=1.
• worker - the ARQ background worker used for deploys and builds.
• vite - the live frontend on http://localhost:8616, proxying /api and /ws to the backend.
• kea - frontend type generation in watch mode.
• redis - local Redis for jobs, logs, websockets and Remote connections.

Open http://localhost:8616 once the backend and Vite panes are ready. In development mode the backend runs database migrations before startup and creates a local .env with a development SECRET_KEY if you do not already have one.

If you prefer to run processes manually, start Redis with either the redis pane in pnpm dev or Flox services:

flox services start redis
pnpm run dev:backend
pnpm run dev:worker
pnpm --dir frontend run dev

Link the backend to FrameOS Cloud

A self-hosted backend can optionally be linked to a FrameOS Cloud account. Open Settings → FrameOS Cloud and click Connect to cloud.frameos.net: the backend shows a short code, you approve it on cloud.frameos.net/device, and the link is made. What it adds, each an Enabled feature you can switch individually:

• Save and share scenes via the cloud (always on): the scene store appears as a repository in every frame's Templates panel, and a Save to private cloud menu item pushes your own scenes to your account, where they stay private until you publish them.
• Cloud backups: after every successful deploy the backend uploads the frame's settings and scenes, plus your scene library, end-to-end encrypted with a key the cloud never sees. Keep the recovery key (FRBK1-…, shown under the switch) in your password manager; after reinstalling the backend, link it again, paste the key, and Restore what you had. There is also a plain Download a local backup (.tar.gz) button that never leaves your machine.
• Cloud login: sign in to this backend with Continue with FrameOS Cloud. You can then turn local password login off; if the link ever goes away, the password comes back by itself, so you can't lock yourself out.

Linking changes nothing about how frames are managed: the backend still deploys over SSH and FrameOS Remote, the cloud never gets a shell or your credentials, and Disconnect (here, or under Account → Backends in the cloud) undoes it at any time. The cloud only learns the backend's version and which features are on.

Next step

Time to prepare your Raspberry Pi: set up the Raspberry.
